THE MAIN CONFIGULATION:
Turbine | Roller ball lead screw | Servo motor |
10.4 inch touch screen computer | Double guide rail |
MAIN SPECIFICATION
MODEL | SQZ-137CTN KD |
Cutting width(mm) | 1370 |
Max.cutting height(mm) | 165 |
Max.cutting length(mm) | 1450 |
Main motor power(kw) | 5.5 |
Net weight(kg) | 4700 |
Width with sideway(mm) | 2870 |
Without sideway(mm) | 2385 |
Machine lenght | 2785 |
Machine height | 1650 |
Front table length(mm) | 735 |
Table height(mm) | 900 |
Clamp pressure min(dan/bs) | 150 |
Max(dan/bs) | 5500 |
Knife thickness(mm) | 13.75 |
Grinding reserve(mm) | 60 |
Without false clamp(mm) | 25 |
With false clamp(mm) | 95 |
Cutting speed(mm) | 45 |
Voltage(three-phase)(v) | 361-339 |
Packing size(L*W*H)(mm) | 2950*1550*2000 |
MAIN PARTS:
No. | Name | Brand Model | Origin |
1 |
Display screen | 10.4 inches color touch screen | beijing |
2 | Motherboard | INVET | shenzhen |
3 | Main motor | zhonglong | zhejiang |
4 | Drive under the knife | Flat worm reducer | tianjin |
5 | Motor driver | YASKAWA | Japan |
6 | Feed lead screw | TBI | Taiwan |
7 | Guide-rail | TBI | Taiwan |
8 | Worktable | Slotless chrome platform with air cushion | HT2500 Casting |
9 | Bearing | /NSK Bearing | Japan |
10 | Sensor | OMORN | Japan |
11 | Travel Switch | /OMORN | Japan |
12 | Air switch | ABB | Switzerland |
13 | Power switch | OMORN | Japan |
14 | Locating switch | OMORN | Japan |
15 | Contacts & disconnector | ABB | /Switzerland |
16 | Host Button | TAYEE | China |
17 | Seals | MERKEL | Japan |
18 | pump Components | MARZOCCHI | Italy |
WHY US:
1. Our brand "SHENDA" is founded since 1986 and well-known in export market since 2008. Europe, South America, Latin America, Southeast Asia, Middle East, Africa etc.
2. Genuine products with excellent quality. Company has always proved the 100% quality.
3. After-sales service and technical assistance: company provides after sales service and technical assistance as per customers' requirement and needs. After-sales service provided engineers available to service machinery overseas.
4. Cost saving: long-life, shock resistant and high reliability bearings with excellent quality and better performance, resulting in increased cost saving.
5. Less cost of purchase: We are the manufacturer directly.
6. Attendant customers queries promptly.
FAQ:
1. Are you a factory or trading company?
We are both a factory and a trading company in this field .
2. What is the terms of payment you accept?
We usually accept the T/T payment, we need 30% of total amount as deposit,pay the 70% balance before delivery, but we can also accept the L/C.
3. Where is your factory located ? How can I visit there?
Our factory located in Beiyu Industrial Zone, Ruian, Zhejiang province, China. Warmly welcome to visit our company.
You can fly to wenzhou airport directly and we will pick you up there.
4. How does your factory do regarding quality control?
Quality is priority. We always regard great importance to quality controlling from the very small thing(even a small screw we will choose the best quality) from the beginning.
